With this posting, I’d like to highlight the most important Statistics & Wait Events on Exadata that a DBA needs to be familiar with in my view. We start with Statistics, retrievable from v$sysstat, for example. For Exadata, we have introduced 43 new Statistics, that start all with ‚cell%‘:
SQL> select name from v$statname where name like 'cell%'; NAME ---------------------------------------------------------------- cell physical IO interconnect bytes cell physical IO bytes saved during optimized file creation cell physical IO bytes saved during optimized RMAN file restore cell physical IO bytes eligible for predicate offload cell physical IO bytes saved by storage index cell smart IO session cache lookups cell smart IO session cache hits cell smart IO session cache soft misses cell smart IO session cache hard misses cell smart IO session cache hwm cell num smart IO sessions in rdbms block IO due to user cell num smart IO sessions in rdbms block IO due to no cell mem cell num smart IO sessions in rdbms block IO due to big payload cell num smart IO sessions using passthru mode due to user cell num smart IO sessions using passthru mode due to cellsrv cell num smart IO sessions using passthru mode due to timezone cell num smart file creation sessions using rdbms block IO mode cell physical IO interconnect bytes returned by smart scan cell num fast response sessions cell num fast response sessions continuing to smart scan cell smart IO allocated memory bytes cell smart IO memory bytes hwm cell num active smart IO sessions cell smart IO sessions hwm cell scans cell blocks processed by cache layer cell blocks processed by txn layer cell blocks processed by data layer cell blocks processed by index layer cell commit cache queries cell transactions found in commit cache cell blocks helped by commit cache cell blocks helped by minscn optimization cell simulated physical IO bytes eligible for predicate offload cell simulated physical IO bytes returned by predicate offload cell CUs sent uncompressed cell CUs sent compressed cell CUs sent head piece cell CUs processed for uncompressed cell CUs processed for compressed cell IO uncompressed bytes cell index scans cell flash cache read hits 43 rows selected.
The in my opinion most important Statistics are marked in red. Now to their meaning:
SQL> connect adam/adam
Connected.
SQL> select * from sales;
* Output suppressed, because I don't want millions of rows in the posting*
select name,value/1024/1024 as mb from v$statname
natural join v$mystat where name in
(
'physical read total bytes',
'cell physical IO interconnect bytes',
'cell physical IO interconnect bytes returned by smart scan'
);
NAME MB
---------------------------------------------------------------- ----------
physical read total bytes 428.4375
cell physical IO interconnect bytes 428.4375
cell physical IO interconnect bytes returned by smart scan 0
The demo table sales is 428 MB in size, large enough to cause a Serial Direct Read and make Smart Scans possible. You see the Statistic ‚cell physical IO interconnect bytes‘ – in this case equal to ‚physical read total bytes‘, because the whole amount of data scanned on the storage layer was sent over the Storage Interconnect (do not confuse this with a RAC Interconnect!) to the Database Layer. Consequently, this was no Smart Scan, because we did no column projection nor filtering. The red Statistic above counts the bytes sent between the Storage Layer and the Database Layer, and v$mystat displays that value only for my session. Let’s do a Smart Scan:
SQL> select * from sales where channel_id=2;
* Output suppressed*
select name,value/1024/1024 as mb from v$statname
natural join v$mystat where name in
(
'physical read total bytes',
'cell physical IO interconnect bytes',
'cell physical IO interconnect bytes returned by smart scan'
);
NAME MB
---------------------------------------------------------------- ----------
physical read total bytes 855.851563
cell physical IO interconnect bytes 506.039314
cell physical IO interconnect bytes returned by smart scan 77.6018143
The values in v$mystat are cumulative for the whole session. You see the value of ‚physical read total bytes‘ has doubled, because we did again a Full Table Scan on the Storage Layer, but ‚cell physical IO interconnect bytes‘ did not double, because the filtering by the WHERE clause was done on the Storage Layer. We needed only to submit about 77 MB to the Database Layer instead, which is also reflected by ‚cell physical IO interconnect bytes returned by smart scan‘. So this Statistic shows the data volume that was sent to the Database Layer on behalf of a Smart Scan – which is supposed to be significantly smaller than ‚physical read total bytes‘ for a Database that does many Full Table Scans resp. Index Fast Full Scans on large Segments.
Storage Indexes have the ability to speed up Full Table Scan dramatically:
SQL> select * from sales where id=4711; PRODUCT CHANNEL_ID CUST_ID AMOUNT_SOLD TIME_ID ID ------------------------- ---------- ---------- ----------- --------- ---------- Oracle Enterprise Edition 3 998 5000 01-NOV-10 4711 SQL> select name,value/1024/1024 as mb from v$statname natural join v$mystat where name in ( 'physical read total bytes', 'cell physical IO interconnect bytes', 'cell physical IO interconnect bytes returned by smart scan' ); NAME MB ---------------------------------------------------------------- ---------- physical read total bytes 1283.26563 cell physical IO interconnect bytes 506.041885 cell physical IO interconnect bytes returned by smart scan 77.6043854
Although the Statistic ‚physical read total bytes‘ again got increased by 428 MB, we see only a very slight increase in ‚cell physical IO interconnect bytes‘ and ‚cell physical IO interconnect bytes returned by smart scan‘, because the Data Volume (containing just one row of interest) sent to the Database Layer was very small. Also, the Smart Scan operation was done very fast, because a Storage Index told the Cells where the ID searched after could not possibly be:
SQL> select name,value/1024/1024 as mb from v$statname
natural join v$mystat where name='cell physical IO bytes saved by storage index';
NAME MB
---------------------------------------------------------------- ----------
cell physical IO bytes saved by storage index 419.742188
The red Statistic shows the Data Volume, the Cells did not need to scan through, because they knew the Data cannot be there. In this case, the vast majority of the table was not scanned (although ‚physical read total bytes‘ counts it as if the Cells scanned the whole table).
The next Statistic is very important for an OLTP Database running on Exadata:
SQL> select name,value from v$sysstat where name in
('physical read total IO requests','cell flash cache read hits');
NAME VALUE
---------------------------------------------------------------- ----------
physical read total IO requests 142476
cell flash cache read hits 32897
If a large amount of ‚physical read total IO requests‘ was satisfied by the blue Statistics value, we can conclude that we have the basis for a high I/O per second (IOPS) rate, because on Flash Storage, we do not experience the latency time related to the positioning of the Read/Write Head as on Spinning Drives. The blue Statistic counts the number of read requests, resolved from Flash Cache.
Wait Events
We introduced 17 new Wait Events for Exadata. Like the statistics, they are visible also on non Exadata Platforms but have no value there. They can be seen in this view:
SQL> select name from v$event_name where name like 'cell%'; NAME ---------------------------------------------------------------- cell smart table scan cell smart index scan cell statistics gather cell smart incremental backup cell smart file creation cell smart restore from backup cell single block physical read cell multiblock physical read cell list of blocks physical read cell manager opening cell cell manager closing cell cell manager discovering disks cell worker idle cell smart flash unkeep cell worker online completion cell worker retry cell manager cancel work request 17 rows selected.
Again, I have highlighted the in my view most important ones. I’d like to give a brief explanation of them:
‚cell smart table scan‘:
Wait Event that occurs during a Smart Scan on a Table.
‚cell smart index scan‘:
Wait Event that occurs during a Smart Scan on an Index (on behalf of a Direct Index Fast Full Scan)
We expect both to be among the Top Wait Events on a Data Warehouse Database, running on Exadata. There is nothing wrong with that; something has to be the Top Wait Event 🙂
‚cell multiblock physical read‘:
This Wait Event occurs most likely because of a conventional Full Table Scan resp. a conventional Index Fast Full Scan (both not offloaded). Typically because the Table resp. the Index was small. It would be surprising to see this as a major Wait Event on a Data Warehouse Database running on Eaxadata, but it will show up regularly on OLTP running on Exadata
‚cell single block physical read‘:
The most likely reason for this is a conventional (not Offloaded) Index Access. Again, we expect to see this Wait Event high on OLTP but low on Data Warehouse Databases, running on Exadata
